Intel Xeon E3-1285LV4 processor 3.4 GHz 6 MB L3
EAN:
0675901347273
Intel Xeon E3-1285LV4. Processor family: Intel® Xeon® E3 v4, Processor socket: LGA 1150 (Socket H3), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by...
Product Description
Product Description
Intel Xeon E3-1285LV4. Processor family: Intel® Xeon® E3 v4, Processor socket: LGA 1150 (Socket H3), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR3-SDRAM, DDR3L-SDRAM. On-board graphics card model: Intel® Iris™ Pro Graphics P6300, Embedded DRAM (eDRAM) memory: 128 MB, Maximum on-board graphics card memory: 32 GB. Market segment: Server, PCI Express configurations: 1x16, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 3.8 GHz
Technical Spec
Technical Spec
Product Description
Intel Xeon E3-1285LV4, Intel® Xeon® E3 v4, LGA 1150 (Socket H3), 14 nm, Intel, E3-1285LV4, 3.4 GHz
Tech Specs
Processor
Processor family
Intel® Xeon® E3 v4
Processor cores
4
Processor socket
LGA 1150 (Socket H3)
Processor lithography
14 nm
Box
No
Cooler included
No
Processor manufacturer
Intel
Processor model
E3-1285LV4
Processor base frequency
3.4 GHz
Processor operating modes
64-bit
Component for
Server/workstation
Processor series
Intel Xeon E3-1200 v4
Processor threads
8
System bus rate
5 GT/s
Processor boost frequency
3.8 GHz
Processor cache
6144 KB
Processor cache type
L3
Thermal Design Power (TDP)
65 W
Stepping
G0
Bus type
DMI
Number of QPI links
0
Memory bandwidth supported by processor (max)
29.8 GB/s
Processor codename
Broadwell
Processor code
SR2B1
Processor ARK ID
88043
Memory
Memory channels
Dual-channel
Maximum internal memory supported by processor
32 GB
Memory types supported by processor
DDR3-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor
1333,1600,1866 MHz
Memory voltage supported by processor
1.5 V
ECC
Yes
Graphics
On-board graphics card
Yes
On-board graphics card model
Intel® Iris™ Pro Graphics P6300
Embedded DRAM (eDRAM) memory
128 MB
Maximum on-board graphics card memory
32 GB
On-board graphics card base frequency
300 MHz
On-board graphics card dynamic frequency (max)
1150 MHz
On-board graphics card burst frequency
1150 MHz
Number of displays supported (on-board graphics)
3
Number of execution units
48
Features
Execute Disable Bit
Yes
Idle States
Yes
Market segment
Server
Maximum number of PCI Express lanes
16
PCI Express slots version
3.0
PCI Express configurations
1x16
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Scalability
1S
CPU configuration (max)
1
Embedded options available
No
Thermal solution specification
PCG 2013B
PCI Express CEM revision
3.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Yes
Intel FDI Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Trusted Execution Technology
Yes
Intel® Turbo Boost Technology 2.0 frequency
3.8 GHz
Intel® Transactional Synchronization Extensions
Yes
Intel Enhanced Halt State
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel TSX-NI
Yes
Intel® OS Guard
Yes
Intel Clear Video Technology
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel TSX-NI version
1.00
Conflict-Free processor
Yes
Intel® vPro™ Platform Eligibility
Yes
Technical details
Product type
Processor
Maximum graphics card memory
32 GB
Supported memory types
DDR3-SDRAM, DDR3L-SDRAM
Logistics data
Harmonized System (HS) code
85423119
Weight & dimensions
Processor package size
37.5 x 37.5 mm
Other features
Intel® Virtualization Technology (Intel® VT)
VT-x, VT-d
Compatibility
Intel Server System R1208RPMSHOR, R1304RPMSHOR, R1304RPOSHBN, R1304RPSSFBN, P4308RPLSHDR, Intel Server Board S1200V3RPL, S1200V3RPM, S1200V3RPO, S1200V3RPS
Maximum internal memory
32768 MB
Cache memory
6 MB
Born on date
Q2'15
Bus bandwidth
5
Bus type units
GT/s
Graphics max dynamic frequency
1.15 GHz
Launch date
Q2'15
Number of graphics cores
3
Product name
Intel Xeon E3-1285L v4 (6M Cache, 3.40 GHz)
Status
Discontinued
Maximum memory
32 GB
Processor brand name
Intel Xeon
Last change
63903513
Product family
Intel Xeon Processor E3 v4 Family
Bus speed
5 GT/s
