APC Easy 3S uninterruptible power supply (UPS) Double-conversion (Online) 15 kVA 15000 W
EAN:
0731304428206
APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 15 kVA, Output power: 15000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 240 V. Form factor: Tower, Product colour: White, Display type: LED....
Product Description
Product Description
0
APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 15 kVA, Output power: 15000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 240 V. Form factor: Tower, Product colour: White, Display type: LED. Compliance certificates: RoHS, Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH. Width: 380 mm, Depth: 928 mm, Height: 1400 mm
APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 15 kVA, Output power: 15000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 240 V. Form factor: Tower, Product colour: White, Display type: LED. Compliance certificates: RoHS, Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH. Width: 380 mm, Depth: 928 mm, Height: 1400 mm
Technical Spec
Technical Spec
Product Description
APC Easy 3S, Double-conversion (Online), 15 kVA, 15000 W, Pure sine, 304 V, 477 V
Tech Specs
Features
UPS topology
Double-conversion (Online)
Output power capacity
15 kVA
Output power
15000 W
Waveform
Pure sine
Input operation voltage (min)
304 V
Input operation voltage (max)
477 V
Input frequency
45/65 Hz
Output operation voltage (min)
380 V
Output operation voltage (max)
415 V
Output frequency
50/60 Hz
Maximum current
28 A
Number of input phases
3
Number of output phases
3
Input power factor
0.99
Output voltage Total Harmonic Distortion (THD)
3%
Input current Total Harmonic Distortion (THD)
3%
Noise level
60 dB
Battery
Battery technology
Sealed Lead Acid (VRLA)
Battery voltage
240 V
Number of batteries supported
3
Design
Form factor
Tower
Product colour
White
Display type
LED
International Protection (IP) code
IP20
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 999.9 m
Non-operating altitude
0 - 15000 m
Certificates
Compliance certificates
RoHS
Certification
CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH
Packaging content
Quick installation guide
Yes
Weight & dimensions
Width
380 mm
Depth
928 mm
Height
1400 mm
Weight
436 kg
Packaging data
Package width
563 mm
Package depth
1014 mm
Package height
1640 mm
Package weight
481 kg
Logistics data
Harmonized System (HS) code
85078000
Other features
Output voltage
400 V
