Cisco Small Business Catalyst 2960X-24PS-L Network Switch, 24 Gigabit Ethernet Ports, 370W PoE Budget, four 1 G SFP Uplink Ports, Enhanced Limited Lifetime Warranty (WS-C2960X-24PS-L)
EAN:
8826585543396
Cisco Small Business Catalyst 2960X-24PS-L Network Switch, 24 Gigabit Ethernet Ports, 370W PoE Budget, four 1 G SFP Uplink Ports, Enhanced Limited Lifetime Warranty (WS-C2960X-24PS-L). Switch type: Managed, Switch layer: L2/L3. Basic switching...
Product Description
Product Description
- Allows stacking of up to 8 switches and 80 Gbps bandwidth with the optional Cisco FlexStack+ module.
- Automatically configures ports based on device type for rapid deployment with Auto Smart Ports.
- Helps enable scalable and dynamic role-based access control with Cisco TrustSec.
- Built for application visibility and control - NetFlow Lite prioritizes business applications.
- The enhanced limited lifetime warranty provides the same terms as Cisco’s standard limited lifetime warranty, but adds next business day delivery of
replacement hardware, where available, and 90 days of 8X5 Cisco Technical Assistance Center (TAC)
support.
Cisco Small Business Catalyst 2960X-24PS-L Network Switch, 24 Gigabit Ethernet Ports, 370W PoE Budget, four 1 G SFP Uplink Ports, Enhanced Limited Lifetime Warranty (WS-C2960X-24PS-L). Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, USB 2.0 ports quantity: 2, Console port: RJ-45. Full duplex. MAC address table: 16000 entries, Switching capacity: 216 Gbit/s. Networking standards: IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Technical Spec
Technical Spec
Product Description
Cisco Small Business Catalyst 2960X-24PS-L Network Switch, 24 Gigabit Ethernet Ports, 370W PoE Budget, four 1 G SFP Uplink Ports, Enhanced Limited Lifetime Warranty (WS-C2960X-24PS-L), Managed, L2/L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Tech Specs
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
MIB support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
24
SFP module slots quantity
4
Console port
RJ-45
USB 2.0 ports quantity
2
Network
Networking standards
IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
Auto-negotiation
Yes
VLAN support
Yes
Virtual LAN features
Private VLAN
Number of VLANs
1023
Data transmission
MAC address table
16000 entries
Switching capacity
216 Gbit/s
Throughput
71.4 Mpps
Number of queues
8
Number of static routes
1000
Jumbo frames support
Yes
Jumbo frames
9216
Security
DHCP features
DHCP server
Access Control List (ACL)
Yes
Access Control List (ACL) rules
3
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, SNMP, SSH
SSH/SSL support
Yes
Authentication
MAC-based authentication, Port-based authentication
Multicast features
Multicast support
Yes
Number of multicast groups filtered
1000
Protocols
Management protocols
SNMPv3
Switching protocols
UDP, TCP, RADIUS/TACACS+
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Black
LED indicators
Yes
Market segment
Business
Safety
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Performance
Physical stacking (units)
8
Built-in processor
Yes
Processor model
AppliedMicro APM8639
Processor frequency
600 MHz
Memory type
DRAM
Internal memory
512 MB
Flash memory
128 MB
Noise level
39 dB
Mean time between failures (MTBF)
324280 h
Power
Power supply included
Yes
Redundant power supply (RPS) support
Yes
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
5 A
Power consumption (typical)
49 W
Power plug type
Type C
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
24
Power over Ethernet plus (PoE+) ports quantity
12
Total Power over Ethernet (PoE) budget
370 W
Other features
Power LED
Yes
Packaging content
WS-C2960X-24PS-L Switch, Accessory Kit, 1 printed document
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
10 - 95%
Storage relative humidity (H-H)
10 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 4000 m
Weight & dimensions
Width
445 mm
Depth
368 mm
Height
45 mm
Weight
5.8 kg
Packaging content
Cables included
AC
User guide
Yes
Packaging data
Package width
469.9 mm
Package depth
549.4 mm
Package height
147.6 mm
Package weight
7.07 kg
Technical details
Products per shipping (inner) case
1 pc(s)
Logistics data
Quantity per pack
1 pc(s)
Country of origin
China
Harmonized System (HS) code
85176990
Products per master (outer) case
1 pc(s)
