Vertiv Avocent 8-Port ACS 8000 with single DC Power Supply - ACS8008SDC-400
EAN:
0636430078878
Vertiv Avocent 8-Port ACS 8000 with single DC Power Supply - ACS8008SDC-400. Management protocols: CLI, HTTP/ HTTPS, SNMP. Authentication method: LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP), Security algorithms: 3DES, 128-bit AES, 192-bit...
Product Description
Product Description
0
Vertiv Avocent 8-Port ACS 8000 with single DC Power Supply - ACS8008SDC-400. Management protocols: CLI, HTTP/ HTTPS, SNMP. Authentication method: LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP), Security algorithms: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3,.... Console port: RJ-45, AC outlet types: C13 coupler. Operating system installed: Embedded LINUX. Dimensions (WxDxH): 438.2 x 241.3 x 44.5 mm, Weight: 3.4 kg
Vertiv Avocent 8-Port ACS 8000 with single DC Power Supply - ACS8008SDC-400. Management protocols: CLI, HTTP/ HTTPS, SNMP. Authentication method: LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP), Security algorithms: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3,.... Console port: RJ-45, AC outlet types: C13 coupler. Operating system installed: Embedded LINUX. Dimensions (WxDxH): 438.2 x 241.3 x 44.5 mm, Weight: 3.4 kg
Technical Spec
Technical Spec
Product Description
Vertiv Avocent 8-Port ACS 8000 with single DC Power Supply - ACS8008SDC-400, CLI, HTTP/ HTTPS, SNMP, LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP), 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3,..., RJ-45, C13 coupler, Embedded LINUX
Tech Specs
Rack mounting
Yes
Internal modem
No
Zero Touch Provisioning (ZTP)
Yes
Web-based management
Yes
Temperature sensor
Yes
Product colour
Black
Event logging
Yes
Management protocols
CLI, HTTP/ HTTPS, SNMP
Authentication method
LOCAL,LDAP,RADIUS,TACACS+ and OneTimePasswords(OTP)
Security algorithms
3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3, SSH, SSH-2
IP address filtering
Yes
One-time password (OTP)
Yes
Console port
RJ-45
Serial ports quantity
8
USB 2.0 ports quantity
8
Ethernet LAN (RJ-45) ports
2
SFP module slots quantity
2
AC outlet types
C13 coupler
Operating system installed
Embedded LINUX
Dimensions (WxDxH)
438.2 x 241.3 x 44.5 mm
Weight
3.4 kg
Power source type
DC
AC input frequency
50 - 60 Hz
Power consumption (typical)
11 W
Input current
0.5 A
DC input voltage
-48 V
Number of power supply units
1
Operating temperature (T-T)
-10 - 60 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
5 - 95%
Certification
FCC Class A, CE Class A (EU), ICES-003 (Canada), VCCI (Japan), RCM (Australia), Customs Union (CU), KCC (Korea), UL (USA), cUL (Canada), EN-60950 (EU), CB, Customs Union (CU)
Internal memory
1000 MB
Flash memory
16000 MB
RAM capacity
1024 MB
RAM type
DDR3L
eMMC capacity
16 GB
Processor family
ARM Cortex-A9
Processor architecture
ARM Cortex-A9
Processor cores
2
Processor frequency
667 MHz
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
Cable types supported
Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Fiber
Safety
UL (USA), cUL (Canada), EN-60950 (EU), CB, Customs Union (CU)
