Intel Core i5-4590S processor 3 GHz 6 MB Smart Cache
EAN:
0675901259774
Intel Core i5-4590S. Processor family: Intel® Core™ i5, Processor socket: LGA 1150 (Socket H3), Processor lithography: 22 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by...
Product Description
Product Description
Intel Core i5-4590S. Processor family: Intel® Core™ i5, Processor socket: LGA 1150 (Socket H3), Processor lithography: 22 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR3-SDRAM, DDR3L-SDRAM. On-board graphics card model: Intel® HD Graphics 4600, Maximum on-board graphics card memory: 2 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, VGA (D-Sub). Market segment: Desktop, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 3.7 GHz
Technical Spec
Technical Spec
Product Description
Intel Core i5-4590S, Intel® Core™ i5, LGA 1150 (Socket H3), 22 nm, Intel, i5-4590S, 3 GHz
Tech Specs
Processor family
Intel® Core™ i5
Processor cores
4
Processor socket
LGA 1150 (Socket H3)
Processor lithography
22 nm
Box
No
Cooler included
No
Processor manufacturer
Intel
Processor model
i5-4590S
Processor base frequency
3 GHz
Processor operating modes
64-bit
Processor generation
4th gen Intel® Core™ i5
Component for
PC
Processor series
Intel Core i5-4500 Desktop Series
Processor threads
4
System bus rate
5 GT/s
Processor boost frequency
3.7 GHz
Processor cache
6144 KB
Processor cache type
Smart Cache
Thermal Design Power (TDP)
65 W
Stepping
C0
Bus type
DMI
Memory bandwidth supported by processor (max)
25.6 GB/s
Processor codename
Haswell
Processor ARK ID
80816
Memory channels
Dual-channel
Maximum internal memory supported by processor
32 GB
Memory types supported by processor
DDR3-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor
1333,1600 MHz
ECC
No
On-board graphics card
Yes
On-board graphics card model
Intel® HD Graphics 4600
Maximum on-board graphics card memory
2 GB
On-board graphics card outputs supported
Embedded DisplayPort (eDP), DisplayPort, HDMI, VGA (D-Sub)
On-board graphics card base frequency
350 MHz
On-board graphics card dynamic frequency (max)
1150 MHz
Number of displays supported (on-board graphics)
3
On-board graphics card DirectX version
11.2/12
On-board graphics card OpenGL version
4.3
On-board graphics card maximum resolution (DisplayPort)
3840 x 2160 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
3840 x 2160 pixels
On-board graphics card maximum resolution (HDMI)
4096 x 2304 pixels
On-board graphics card maximum resolution (VGA)
1920 x 1200 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)
24 Hz
On-board graphics card refresh rate at maximum resolution (VGA)
60 Hz
On-board graphics card ID
0x412
Execute Disable Bit
Yes
Idle States
Yes
Thermal Monitoring Technologies
Yes
Market segment
Desktop
Maximum number of PCI Express lanes
16
PCI Express slots version
3.0
PCI Express configurations
1x16, 2x8, 1x8+2x4
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Bandwidth
5 MB/s
Scalability
1S
CPU configuration (max)
1
Embedded options available
Yes
Graphics & IMC lithography
2 nm
Thermal solution specification
PCG 2013C
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159
Intel® Anti-Theft Technology (Intel® AT)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Identity Protection Technology (Intel® IPT)
Yes
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel FDI Technology
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Insider™
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Trusted Execution Technology
Yes
Intel® Turbo Boost Technology 2.0 frequency
3.7 GHz
Intel® Transactional Synchronization Extensions
No
Intel Enhanced Halt State
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Secure Key
Yes
Intel TSX-NI
No
Intel Stable Image Platform Program (SIPP)
Yes
Intel® OS Guard
Yes
Intel 64
Yes
Intel Identity Protection Technology version
1.00
Intel Secure Key Technology version
1.00
Intel Small Business Advantage (SBA) version
1.00
Intel Stable Image Platform Program (SIPP) version
1.00
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel TSX-NI version
0.00
Conflict-Free processor
Yes
Intel® vPro™ Platform Eligibility
Yes
Tcase
71.35 °C
Product type
Processor
Supported memory types
DDR3-SDRAM, DDR3L-SDRAM
Maximum graphics card memory
2 GB
Harmonized System (HS) code
85423119
Package type
Retail box
Processor package size
37.5 x 37.5 mm
Intel® Virtualization Technology (Intel® VT)
VT-d, VT-x
Maximum internal memory
32768 MB
Video decoding
Yes
Generation
4th Generation
Bus bandwidth
5
Bus type units
GT/s
Launch date
Q2'14
Maximum resolution & refresh rate (DisplayPort)
3840x2160@60Hz
Maximum resolution & refresh rate (HDMI)
4096x2304@24Hz
Maximum resolution & refresh rate (Integrated Flat Panel)
3840x2160@60Hz
Maximum resolution & refresh rate (VGA)
1920x1200@60Hz
Number of graphics cores
20
Status
Launched
Maximum memory
32 GB
Processor brand name
Intel Core i5
Intel Core i5 Processor
Last change
63903513
Product family
4th Generation Intel Core i5 Processors
Bus speed
5 GT/s
Processor ID
0x412
Servicing status
End of Servicing Lifetime
End of servicing updates date
Wednesday, June 30, 2021
Graphics output
eDP/DP/HDMI/VGA
