HPE ProLiant DL560 Gen10 server 0 GB Rack (2U) Intel® Xeon® Platinum 8268 2.9 GHz 512 GB DDR4-SDRAM 1600 W
EAN:
0190017272511
HPE ProLiant DL560 Gen10. Processor family: Intel® Xeon® Platinum, Processor frequency: 2.9 GHz, Processor model: 8268. Internal memory: 512 GB, Internal memory type: DDR4-SDRAM, Memory layout (slots x size): 16 x 32 GB. Total storage capacity:...
Product Description
Product Description
HPE ProLiant DL560 Gen10. Processor family: Intel® Xeon® Platinum, Processor frequency: 2.9 GHz, Processor model: 8268. Internal memory: 512 GB, Internal memory type: DDR4-SDRAM, Memory layout (slots x size): 16 x 32 GB. Total storage capacity: 0 GB, HDD size: 2.5", HDD interface: Serial ATA III, Serial Attached SCSI (SAS). Ethernet LAN, Cabling technology: 10/100/1000Base-T(X). Power supply: 1600 W. Chassis type: Rack (2U)
Technical Spec
Technical Spec
Product Description
HPE ProLiant DL560 Gen10, 2.9 GHz, 8268, 512 GB, DDR4-SDRAM, 0 GB, Rack (2U)
Tech Specs
Processor
Processor family
Intel® Xeon® Platinum
Processor manufacturer
Intel
Processor model
8268
Processor frequency
2.9 GHz
Processor generation
2nd Generation Intel® Xeon® Scalable
Processor boost frequency
3.9 GHz
Processor cores
24
Processor cache
35.75 MB
Motherboard chipset
Intel® C621
Number of processors installed
4
Thermal Design Power (TDP)
205 W
Processor cache type
Smart Cache
Maximum number of SMP processors
4
Compatible processor series
Intel® Xeon®
Processor socket
LGA 3647 (Socket P)
Supported processor sockets
LGA 3647 (Socket P)
Processor lithography
14 nm
Processor threads
48
Processor operating modes
64-bit
Processor codename
Cascade Lake
Tcase
84 °C
Maximum internal memory supported by processor
1.02 TB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2933 MHz
Execute Disable Bit
Yes
Maximum number of PCI Express lanes
48
Processor package size
76.0 x 56.5 mm
Supported instruction sets
AVX-512
Scalability
S8S
Embedded options available
No
Memory
Internal memory
512 GB
Internal memory type
DDR4-SDRAM
Maximum internal memory
1.54 TB
Memory slots
48x DIMM
Memory layout (slots x size)
16 x 32 GB
Storage
Total storage capacity
0 GB
RAID support
Yes
Optical drive type
No
Number of HDDs installed
0
HDD interface
Serial ATA III, Serial Attached SCSI (SAS)
HDD size
2.5"
Number of HDDs supported
16
Supported RAID controllers
Smart Array P816i-a SR Gen10
Hot-Plug support
Yes
Supported storage drive interfaces
SAS, Serial ATA III
Graphics
On-board graphics card model
Not available
Network
Ethernet LAN
Yes
Cabling technology
10/100/1000Base-T(X)
Ethernet interface type
Gigabit Ethernet
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
VGA (D-Sub) ports quantity
2
Serial ports quantity
1
Expansion slots
PCI Express slots version
3.0
Design
Chassis type
Rack (2U)
Product colour
Black, Silver
Rack mounting
Yes
Redundant fans support
Yes
Performance
Performance management
HPE iLO 5 ASIC
Software
Operating system installed
No
Compatible operating systems
Windows Server 2012 R2
Windows Server 2016
VMware ESXi 6.0 U3
VMware ESXi 6.5 & U1
Red Hat Enterprise Linux (RHEL) 6.9 & 7.3
SUSE Linux Enterprise Server (SLES) 11 SP4 & 12 SP2
CentOS 6.9 & 7.3
Processor special features
Enhanced Intel SpeedStep Technology
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Trusted Execution Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel TSX-NI
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Processor ARK ID
192481
Power
Redundant power supply (RPS) support
No
Power supply
1600 W
Number of main power supplies
2
Power supply input frequency
50 - 60 Hz
Logistics data
Harmonized System (HS) code
84714100
Sustainability
Sustainability certificates
ENERGY STAR
Weight & dimensions
Width
445.5 mm
Depth
754.7 mm
Height
87.5 mm
Weight
34.1 kg
