HPE Aruba Networking Aruba 2530-48G Managed L2 Gigabit Ethernet (10/100/1000) 1U Grey
EAN:
4053162624306
HPE Aruba Networking Aruba 2530-48G. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000...
Product Description
Product Description
0
HPE Aruba Networking Aruba 2530-48G. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u. Rack mounting, Form factor: 1U
HPE Aruba Networking Aruba 2530-48G. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u. Rack mounting, Form factor: 1U
Technical Spec
Technical Spec
Product Description
HPE Aruba Networking Aruba 2530-48G, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U
Tech Specs
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
SFP module slots quantity
4
Network
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring
Yes
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Rate limiting
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
Auto-sensing
Yes
VLAN support
Yes
Data transmission
MAC address table
16000 entries
Switching capacity
104 Gbit/s
Throughput
77.3 Mpps
Latency (10-100 Mbps)
7.4 µs
Latency (1 Gbps)
2.3 µs
Jumbo frames support
Yes
Packet buffer memory
3 MB
Security
DHCP features
DHCP server
Access Control List (ACL)
Yes
SSH/SSL support
Yes
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Grey
Performance
Virtual stacking (units)
16
Built-in processor
Yes
Processor frequency
800 MHz
Memory type
DDR3-SDRAM
Internal memory
256 MB
Flash memory
128 MB
Power
Power source
AC
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
59.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
15 - 95%
Storage relative humidity (H-H)
15 - 90%
Heat dissipation
203 BTU/h
Weight & dimensions
Width
443 mm
Depth
254 mm
Height
44.5 mm
Weight
3.08 kg
Logistics data
Harmonized System (HS) code
85176990
