Lenovo 4XG7A14812, Intel Xeon Silver, 2.1 GHz, LGA 3647, Server/Workstation, 14 nm, 64-bit
Tech Specs
Intel® Turbo Boost Technology|http
//images.icecat.biz/img/feature_logo/61-5887.png|Higher Performance When You Need It Most
Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.
Intel® vPro™ Technology|http
Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.
Intel® vPro™ Technology|http
Processor
Processor family
Intel Xeon Silver
Processor frequency
2.1 GHz
Processor cores
8
Processor socket
LGA 3647
Component for
Server/Workstation
Processor lithography
14 nm
Processor model
4208
Processor threads
16
Processor operating modes
64-bit
Processor series
Intel Xeon Silver 4000 Series
Processor cache
11 MB
Processor cache type
Smart Cache
Processor boost frequency
3.2 GHz
Bus type
UPI
Processor codename
Cascade Lake
Memory
Memory channels
Hexa
Maximum internal memory supported by processor
1000 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
ECC
Y
Graphics
On-board graphics adapter
N
Discrete graphics adapter
N
On-board graphics adapter model
Not available
Discrete graphics adapter model
Not available
Power
Thermal Design Power (TDP)
85 W
Features
Execute Disable Bit
Y
Maximum number of PCI Express lanes
48
PCI Express slots version
3.0
Supported instruction sets
AVX-512
Scalability
2S
Embedded options available
N
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Turbo Boost Technology
2.0
Intel® vPro™ Technology
Y
Intel® AES New Instructions (Intel® AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
Intel® Speed Shift Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel TSX-NI
Y
Intel 64
Y
Intel Virtualization Technology (VT-x)
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Turbo Boost Max Technology 3.0
N
Operational conditions
Tcase
78 °C
Weight & dimensions
Processor package size
76 x 56.5 mm
Other features
Compatibility
ThinkSystem ST550
