StarTech.com Cisco Meraki MA-SFP-1GB-SX Compatible SFP Transceiver Module - 1000BASE-SX
EAN:
0065030868655
1000 Mbps (1 Gbps) ! Multi Mode Fiber ! LC ! 550 m (1804 ft) ! Lifetime Warranty
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand...
Product Description
Product Description
1000 Mbps (1 Gbps) ! Multi Mode Fiber ! LC ! 550 m (1804 ft) ! Lifetime Warranty
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 550m (1804 ft).
Technical Specifications:
Wavelength: 850nm
Maximum Data Transfer Rate: 1.25 Gbps
Type: Multi Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 550m (1804 ft)
MTBF: 1,967,709 hours
Power Consumption: Less than 1.2 Watts
Digital Diagnostics Monitoring (DDM): Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
- 100% compatibility with Cisco Meraki MA-SFP-1GB-SX guaranteed
- StarTech.com SFP modules are backed by a lifetime warranty
- Meets or exceeds OEM specifications and Multi-Source Agreement (MSA) industry standards
Technical Spec
Technical Spec
Product Description
StarTech.com Cisco Meraki MA-SFP-1GB-SX Compatible SFP Transceiver Module - 1000BASE-SX, 1250 Mbit/s, SFP, LC, IEEE 802.3z, SX, Fiber optic
Tech Specs
Networking
Maximum data transfer rate
1250 Mbit/s
Interface type
SFP
Fiber optic connector
LC
Networking standards
IEEE 802.3z
SFP transceiver type
SX
Performance
Cable type
Fiber optic
Multi-mode fiber (MMF) supported
Y
Wavelength
850 nm
Product colour
Silver
Housing material
Aluminium
Hot-swap
Y
Maximum transfer distance
550 m
Mean time between failures (MTBF)
3381761 h
Duplex system
Full
Full duplex
Y
Country of origin
China
Digital Diagnostics Monitoring (DDM)
Y
Power
Power consumption (typical)
1 W
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
13.7 mm
Depth
56.6 mm
Height
12.5 mm
Weight
14 g
Package width
119 mm
Package depth
94 mm
Package height
33 mm
Package weight
42 g
Certificates
Certification
CE, FCC, UR
RoHS compliance
Y
Packaging content
Number of products included
1 pc(s)
