Tripp Lite SMX1200XLHGL SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation
EAN:
0037332224798
Tripp Lite SMX1200XLHGL SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 750 W. AC outlet types: C13 coupler,...
Product Description
Product Description
0
Tripp Lite SMX1200XLHGL SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 750 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery voltage: 36 V, Typical backup time at full load: 11 min, Typical backup time at half load: 27.5 min. Form factor: Tower, Product colour: Grey, Housing material: Polyvinyl chloride (PVC). Width: 190.5 mm, Depth: 229.9 mm, Height: 322.6 mm
Tripp Lite SMX1200XLHGL SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 750 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery voltage: 36 V, Typical backup time at full load: 11 min, Typical backup time at half load: 27.5 min. Form factor: Tower, Product colour: Grey, Housing material: Polyvinyl chloride (PVC). Width: 190.5 mm, Depth: 229.9 mm, Height: 322.6 mm
Technical Spec
Technical Spec
Product Description
Tripp Lite SMX1200XLHGL SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation, Line-Interactive, 1 kVA, 750 W, 230 V, 230 V, 220 V
Tech Specs
Features
UPS topology
Line-Interactive
Output power capacity
1 kVA
Output power
750 W
Input operation voltage (min)
230 V
Input operation voltage (max)
230 V
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Output frequency regulation
50 - 60 Hz
Surge energy rating
340 J
Number of input phases
1
Ports & interfaces
AC outlet types
C13 coupler
Power plug
C14 coupler
AC outlets quantity
6 AC outlet(s)
USB port
Yes
Serial interface
Yes
Battery
Battery voltage
36 V
Typical backup time at full load
11 min
Typical backup time at half load
27.5 min
Design
Form factor
Tower
Product colour
Grey
Housing material
Polyvinyl chloride (PVC)
LED indicators
Yes
Operational conditions
Operating temperature (T-T)
32 - 104 °C
Storage temperature (T-T)
5 - 122 °C
Operating relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
190.5 mm
Depth
229.9 mm
Height
322.6 mm
Weight
15.9 kg
Packaging data
Package width
309.9 mm
Package depth
339.9 mm
Package height
469.9 mm
Package weight
17.4 kg
Logistics data
Harmonized System (HS) code
85078000
Master (outer) case width
309.9 mm
Master (outer) case length
339.9 mm
Master (outer) case height
469.9 mm
Master (outer) case gross weight
17.4 kg
Products per master (outer) case
1 pc(s)
Country of origin
China
