StarTech.com Dell EMC SFP-1G-SX Compatible SFP Transceiver Module - 1000Base-SX
EAN:
0065030883139
1000 Mbps (1 Gbps) ! Multi Mode Fiber ! LC ! 550 m (1804 ft) ! Lifetime Warranty
The SFP1GSXEMCST is a Dell EMC SFP-1G-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Dell EMC brand switches and...
Product Description
Product Description
1000 Mbps (1 Gbps) ! Multi Mode Fiber ! LC ! 550 m (1804 ft) ! Lifetime Warranty
The SFP1GSXEMCST is a Dell EMC SFP-1G-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Dell EMC brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000Base-SX compliant networks, with a maximum distance of up to 500 m (1640 ft)).
Technical Specifications:
Wavelength: 850nm
Maximum Data Transfer Rate: 1000 Mbps (1 Gbps)
Type: Multi Mode
Connection Type: LC Connector
Maximum Transfer Distance: 550 m (1804 ft)
MTBF: 53,972,659 hours
Power Consumption: Low power consumption
Digital Diagnostics Monitoring (DDM): Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
- 100% Compatibility with Dell EMC SFP-1G-SX guaranteed
- StarTech.com SFP modules are backed by a lifetime warranty
- Meets or exceeds OEM specifications and Multi-Source Agreement (MSA) industry standards
Technical Spec
Technical Spec
Product Description
StarTech.com Dell EMC SFP-1G-SX Compatible SFP Transceiver Module - 1000Base-SX, Fiber optic, 1000 Mbit/s, SFP, LC, SX, 550 m
Tech Specs
Performance
SFP transceiver type
Fiber optic
Maximum data transfer rate
1000 Mbit/s
Interface type
SFP
Multi-mode fiber (MMF) supported
Y
Fiber optic connector
LC
SFP transceiver standard
SX
Maximum transfer distance
550 m
Wavelength
850 nm
Fiber ethernet cabling technology
1000BASE‑SX
Duplex system
Full
Digital Diagnostics Monitoring (DDM)
Y
Features
Product colour
Silver
Hot-swap
Y
Mean time between failures (MTBF)
53972659 h
RoHS compliance
Y
Brand compatibility
Dell
Compatible products
SFP-1G-SX
Certification
CE, FCC, UL, REACH
Weight & dimensions
Width
58.4 mm
Depth
13.9 mm
Height
12.6 mm
Weight
30 g
Packaging data
Number of products included
1 pc(s)
Package width
90 mm
Package depth
115 mm
Package height
31 mm
Package weight
50 g
