Product Description
Product Description
- The HPE Storage Fibre Channel Switch B-series SN6700B delivers increased performance through a combination of improved throughput and low latency across 64Gb links in hyper-scale virtualization, large cloud infrastructures, and growing flash-based storage environments.
Improved performance of NVMe storage with 50% lower switching latency than 32Gb. Latency for locally switched ports is 460ns including forward error correction (FEC). [1]
With 48 SFP+ ports and 8 DD ports, it can scale up to 64 device ports for an aggregate throughput of 4.096Tbps. [2] - The HPE Storage Fibre Channel Switch B-series SN6700B scales up to 64 device ports in an efficiently designed 1U form factor, delivering increased port density and space utilization for simplified scalability.
Each of the 48 SFP+ ports and 8 DD ports supports 8, 10, 16, 32, and 64Gb FC speeds.
Provides flexibility to utilize high-speed 64Gb and 32Gb optics on demand to meet growing data center needs and provide backward compatibility to older infrastructures.
HPE SN6700B 64Gb 56/24 24-port 32Gb Short Wave SFP28 Integrated Fibre Channel Switch. Switch type: Managed. Switching capacity: 64 Gbit/s. Rack mounting, Form factor: 1U
Technical Spec
Technical Spec
Product Description
HPE SN6700B 64Gb 56/24 24-port 32Gb Short Wave SFP28 Integrated Fibre Channel Switch, Managed, Rack mounting, 1U
Tech Specs
Management features
Switch type
Managed
Ports & interfaces
Fiber ports quantity
32
Fiber optic connector
SFP28
SFP28 ports quantity
32
Data transmission
Switching capacity
64 Gbit/s
Design
Rack mounting
Yes
Form factor
1U
Product colour
Silver
Power
Power supply included
No
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
