Synology RackStation RS2818RP+ NAS/storage server Rack (3U) Intel Atom® C3538 4 GB DDR4 0 TB Black
EAN:
4711174722907
Synology RackStation RS2818RP+. Type: NAS. Chassis type: Rack (3U). Device class: Small & Medium Business. Processor family: Intel Atom®, Processor model: C3538, Processor frequency: 2.1 GHz. Internal memory: 4 GB, Internal memory type: DDR4....
Product Description
Product Description
Synology RackStation RS2818RP+. Type: NAS. Chassis type: Rack (3U). Device class: Small & Medium Business. Processor family: Intel Atom®, Processor model: C3538, Processor frequency: 2.1 GHz. Internal memory: 4 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB
Technical Spec
Technical Spec
Product Description
Synology RackStation RS2818RP+, NAS, Rack (3U), Intel Atom®, C3538, 4 GB, DDR4
Tech Specs
Storage
Storage drives installed
No
Total installed storage capacity
0 TB
Number of storage drives installed
0
Number of storage drives supported
16
Installed storage drive type
No
Supported storage drive types
HDD & SSD
Storage drive capacity
0 GB
RAID support
Yes
Supported storage drive interfaces
Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported
2.5,3.5"
Maximum supported storage capacity
192 TB
RAID levels
0, 1, 5, 6, 10, JBOD
Hot-swap drive bays
Yes
Supported file systems
FAT32, HFS+, NTFS, ext3, ext4
Processor
Processor family
Intel Atom®
Processor manufacturer
Intel
Processor model
C3538
Processor frequency
2.1 GHz
Processor boost frequency
2.1 GHz
Processor cores
4
Processor threads
4
Processor cache
8 MB
CPU configuration (max)
1
ECC supported by processor
Yes
PCI Express slots version
3.0
Processor cache type
Smart Cache
Processor code
SR3L7
Processor codename
Denverton
Processor lithography
14 nm
Processor operating modes
64-bit
Processor package size
34 x 28 mm
Processor socket
BGA 1310
Stepping
B1
Tcase
87 °C
Tjunction
100 °C
Thermal Design Power (TDP)
15 W
Maximum internal memory supported by processor
256 GB
Conflict-Free processor
Yes
Memory
Internal memory
4 GB
Internal memory type
DDR4
Maximum RAM supported
64 GB
Memory slots
4
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi
No
DHCP client
Yes
DHCP server
Yes
Jumbo frames support
Yes
iSCSI support
Yes
Auto MDI/MDI-X
Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB port
Yes
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
Fiber ports quantity
0
Design
Chassis type
Rack (3U)
Cooling type
Active
Product colour
Black
Number of fans
3 fan(s)
Fan diameter
8 cm
Drive bay locking
Yes
LED indicators
Yes
Built-in display
No
Performance
Type
NAS
Device class
Small & Medium Business
Backup function
Yes
Backup features
Cloud, iSCSI LUN
Multilingual support
Yes
Noise level
51 dB
Access Control List (ACL)
Yes
Built-in FTP server
Yes
Power
Power supply location
Built-in
Power supply unit (PSU) capacity
500 W
Number of power supply units
2
Power consumption (typical)
138.1 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Weight & dimensions
Width
485 mm
Depth
656.5 mm
Height
132.3 mm
Weight
17.4 kg
Packaging content
Cables included
AC, LAN (RJ-45)
Quick installation guide
Yes
Processor special features
Embedded options available
Yes
Execute Disable Bit
Yes
Intel QuickAssist Technology
Yes
Intel Secure Boot
Yes
Intel Secure Boot Technology version
1.00
Intel Secure Key Technology version
1.00
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel® Turbo Boost Technology
No
Maximum number of PCI Express lanes
12
Number of QPI links
0
Memory channels supported by processor
Dual
Memory types supported by processor
DDR4-SDRAM
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Operating relative humidity (H-H)
-20 - 60%
Storage temperature (T-T)
5 - 95 °C
Storage relative humidity (H-H)
5 - 95%
Logistics data
Harmonized System (HS) code
84714100
Other features
Compliance certificates
RoHS
Processor ARK ID
97929
