Ubiquiti UniFi US-8-150W network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
EAN:
5395481609435
Ubiquiti UniFi US-8-150W. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. Switching capacity: 20 Gbit/s....
Product Description
Product Description
0
Ubiquiti UniFi US-8-150W. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Wall mountable
Ubiquiti UniFi US-8-150W. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Wall mountable
Technical Spec
Technical Spec
Product Description
Ubiquiti UniFi US-8-150W, Managed, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable
Tech Specs
Management features
Switch type
Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity
0
SFP module slots quantity
2
Console port
RJ-45
Network
Networking standards
IEEE 802.3af, IEEE 802.3at
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
Auto-sensing
Yes
VLAN support
Yes
Virtual LAN features
Tagged VLAN
Data transmission
Switching capacity
20 Gbit/s
Throughput
14.88 Mpps
Jumbo frames support
Yes
Design
Product colour
White
Reset button
Yes
LED indicators
Activity, Data, Link, PoE, Speed
Wall mountable
Yes
Performance
Built-in processor
Yes
Processor frequency
400 MHz
Power
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
20 W
Power consumption (max)
150 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE) voltage range
50 - 57 V
Power over Ethernet (PoE) power per port
34.2 W
Total Power over Ethernet (PoE) budget
150 W
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
204 mm
Depth
235 mm
Height
43 mm
Weight
1.7 kg
Packaging content
Cables included
AC
Quick start guide
Yes
Rack mount kit
Yes
Packaging data
Mounting brackets included
Yes
Screws included
Yes
Certificates
Certification
CE, FCC, IC
Logistics data
Harmonized System (HS) code
85176990
